Name: 【SG20-E112-6D】Magnetic Track Diffusion Light
Brand: SmartGlow Magnetic Track Light
SKU: SG20-E112/220/328/436-6/12/18/24D
Availability: InStock
Rating: 5 (1 reviews)

No.SG20-E112/220/328/436-6/12/18/24D

Magnetic track LED diffuse lights use diffuse design to spread soft, glare free light for soft illumination. It seamlessly integrates with the dimmable track light rail system, adjusting brightness to match mood from comfortable living rooms to busy offices. When paired with a concealed magnetic track light track, it can maintain a clean installation, hide the track, and easily reposition without the need for tools.
This LED track light is designed with a 48V voltage to ensure safe operation and zero risk of electric shock. As a track light, it can be easily installed on magnetic tracks. The 48v intelligent magnetic track light supports intelligent control, allowing you to adjust brightness and color temperature through applications or voice commands.

Power:

12W

18W

24W

Size:

L112*W22*H25mm

L220*W22*H25mm

L328*W22*H25mm

L436*W22*H25mm

Color:

Black

White

CCT:

3000K

4000K

6000K

GET A QUOTE

Description
Feature
Specifications

This track light is compatible with the SG20 series magnetic track rail.

This embedded magnetic track lighting system can easily upgrade your ceiling lighting, creating a simple and smooth visual effect. The embedded track is flush with the ceiling, presenting a modern architectural aesthetic; Magnetic lamps can be easily installed, moved, or replaced without any tools. This system is suitable for living rooms, stairs, galleries, and commercial spaces, providing ultimate flexibility and allowing you to freely adjust the lighting layout as the space changes.

The stepless dimming function refers to the ability to adjust the color temperature and brightness of the light. The color temperature can be freely adjusted between warm white light, neutral white light, and cool white light, and the brightness adjustment range is 10% to 100%.

Main functions
Embedded track: Create a simple, flush appearance.

Magnetic buckle design: Simply place the light fixture near the track for installation - a powerful magnet can immediately lock it in place.

Flexible adjustment: can freely slide or reposition spotlights, linear light strips, and wall washers.

Strong magnetic attraction: safe and reliable, but easy to disassemble for maintenance.

Professional lighting data: IES files can be provided upon request; Please contact customer service for details.

ltem No.	SG20-E112-6D	SG20-E220-12D	SG20-E328-18D	SG20-E328-24D
Powwer	6W	12W	18W	24W
Size	L112W22H25mm	L220W22H25mm	L328W22H25mm	L436W22H25mm
Color	Black/White
Voltage	DC48V
Beam Angle	60°
LED Brand	OSRAM
CCT	3000K/4000K/6000K
Compatible Devices	Automatic signal transmission and mode synchronization; Supports smartphone apps and third-party voice control (requires 2.4G gateway); Can be used in conjunction with Amazon Alexa and Google Assistant.
IP protection level	IP20 non waterproof
